| Raw Material | Rolled Steel | PPGI/GI |
| Yeild Strength | 500 MPA |
| Coil Width (mm) | 1220 |
| Rolling Thickness | 0.4 - 0.7 mm |
| Effective Width (mm) | 1010 |
| Common Use (mm) | 0.5 |
| Fielding Platform | Guide Pillar | 45# Steel Precision, Smoothly |
| Manual Pre-cut | Cr12 Blade, pre-cutting for change another steel coil |
| Roll Forming Machine | Frame Structure | H-Beam welded and stand wall |
| Sidewall | 16mm Carbon Steel Plate |
| Steel/Bar | 8.8 grade / 25mm Galvanized |
| Rolled Station | 20 Steps |
| Roller Shaft | 80mm 45# Steel with key-way |
| Shaft Material | 45# Steel Solid, Precision |
| Roller Info. | 45# Harden Chrome Plated |
| Transmission | Chain |
| Motor Power | 11 KW |
| Reducer Type | 5#, 1:29 |
| Output Speed | About 20-30 m/min |
| Cutting System | Frame Structure | Carbon Steel, Single Cylinder |
| Cutting Type | Hydraulic Stop to Cut |
| Cut Performance | Scrap Without Deformation |
| Cutting Blade | Cr12Mov, hardness 60-62 C |
| Hydraulic System | Installation | Inside, easy for operation |
| Pump Motor | From Lifter |
| Computer System | Electrical Control | Delta PLC, Delta Inverter |
| Length Control | Rotary Encoder from Omron |
| Length Tolerance | 10 +- 1.5mm |
| Touch Screen | Delta |
| Low Voltage Components | Limit Switch / Contractor / Relay (Schneider) |
| Voltage | 3 Phases 415V 60Hz |
